Built / Yard | 2008 |
Design | UT 712 L |
Flag | NIS |
LOA | 78.3m |
Breadth Moulded | 17.2m |
Yard | Aker Brevik |
Main Class | +1A1, SF, E0, DK(+), HL(2,5), TUG, SUPPLY VESSELl, CLEAN, DYNPOS-AUTR, FiFi I, TMON |
Classification Society | DNV GL |
Dynamic Positioning | DP 2 from Kongsberg |
Total Capacity | 28 Persons |
Bollard Pull | 183mt |
Deck Dimensions | 540m² (37,5m x 14,4m) |
Deck Load | 900mt |
Deck Strength | 10mt/m² |
Draft (max) | 6.989m + 1.02m Skeg/Nozzle |
Drill Water / WB | 1231m³ / 7743bbls |
Fuel Oil | 1062m³ / 6680bbls |
Deadweight | 2913mt (d=6,989m) |
Total BHP | 15950 BHP |
Towing/Working Winch Brake (Static/Band Brake) | 550mt |
Towing/Working Winch No 2 Brake (Static/Band Brake) | 550mt |
Secondary Winch Fibre Capacity - 160mm | 1 x 2190m of 160mm |
Chain Locker | 4x98m³ = 392m³ |
Gypsies | 2 x 76mm, 2 x 84mm |
Shark Jaws | 2 x 750mt MWL - Karm |
Tow Pins | 4 x 250mt MWL - Karm |
Secondary Winch Number of Drums | 1 Drums |
Secondary Winch Brake | 170mt |
Secondary Winch Max Weight | 100mt |
Pot Water | 741m³ / 4661bbls |
