Built |
2007 |
Design |
UT 712 L |
Flag |
Isle og Man |
LOA |
78.3m |
Breadth Moulded |
17.2m |
Yard |
Brevik |
Main Class |
+1A1, SF, E0, DK(+), HL(2,5), Tug, Supply Vessel, Clean, Dynpos-AUTR, FiFi II, TMON |
Classification Society |
DNV GL |
Dynamic Positioning |
DP 2 from Kongsberg |
Accommodation |
28 Persons |
Bollard Pull |
184.82mt |
Deck Dimensions |
540m² (37,5m x 14,4m) |
Deck Load |
900mt |
Deck Strength |
10mt/m² |
Draft (max) |
7m + 1.02m Skeg/Nozzle |
Drill Water / WB |
1231m³ / 7743bbls |
Fuel Oil |
1060m³ / 6667bbls |
Deadweight |
2,350mt (d=7m) |
Total BHP |
16157 BHP |
Towing/Working Winch Brake (Static/Band Brake) |
550mt |
Towing/Working Winch No 2 Brake (Static/Band Brake) |
550mt |
Secondary Winch Fibre Capacity - 160mm |
1 x 2190m of 160mm |
Chain Locker |
4x98m³ = 392m³ |
Gypsies |
2 x 76mm, 2 x 84mm, 1 x 90mm |
Shark Jaws |
2 x 750mt MWL - Karm |
Tow Pins |
4 x 250mt MWL - Karm |
Secondary Winch Number of Drums |
1 Drums |
Secondary Winch Brake |
170mt |
Secondary Winch Max Weight |
100mt |
Pot Water |
741m³ / 4661bbls |
