PSV

Normand Surfer

  • 960m2
  • 2537mt
Built / Yard 2014
Design PX 105
Yard Zhejijang Shipbuilding
Flag CYP
LOA 89m
Breadth Moulded 19m
Deck Dimensions 960m² (60m x 16m)
Deck Load 2537mt
Main Class +1A1, SF, E0, DK(+), HL(2,8), OFFSHORE SERVICE VESSELl, LFL*, COMF-V(3), CLEAN DESIGN, OILREC, DYNPOS-AUTR, NAUT OSV(A), ICE-C
Classification Society DNV GL
Draft (max) 6,60m + 0m Skeg/Nozzle
Deadweight 4459mt (d=6,60 m)
Deck Strength 10 t/m2 aft fr. 49. fwd fr. 49: 5mt/m²
Consumption at Service Speed 16m³ / 24hrs @ 12Knots
Consumption at Economy Speed 10m³ / 24hrs @ 10Knots
Base Oil 225m³ / 1415bbls
Brine 369m³ / 2321bbls
Drill Water / WB 2191m³ / 13781bbls
Dry Bulk 320m³ / 11299cuft (5 tanks)
Fuel Oil 1076m³ / 6768bbls
Methanol 146m³ / 918bbls
Mud 870m³ / 5472bbls
Pot Water 584m³ / 3673bbls
Accommodation 26 Persons
