Built |
2010 |
Design |
AH 12 |
Flag |
NOR |
LOA |
95m |
Breadth Moulded |
24m |
Yard |
STX Brattvåg |
Main Class |
+1A1, CLEAN DESIGN, COMF-V(3), SF, DK(+), DYNPOS-AUTR, E0, HELDK, HL(2,8), NAUT OSV(A), SUPPLY VESSELl, TMON, Tug |
Classification Society |
DNV GL |
Dynamic Positioning |
DP 2 from Kongsberg |
Accommodation |
70 Persons |
Bollard Pull |
338mt |
Deck Dimensions |
756m² (36m x 21m) |
Deck Load |
2800mt |
Deck Strength |
10mt/m² |
Draft (max) |
7,8m + 0m Skeg/Nozzle |
Drill Water / WB |
3711m³ / 23342bbls |
Fuel Oil |
1994m³ / 12542bbls |
Deadweight |
4710mt (d=7,8m) |
Total BHP |
32600 BHP |
Special Handling Brake (Static/Band Brake) |
600mt |
Towing/Working Winch Brake (Static/Band Brake) |
750mt |
Towing/Working Winch No 2 Brake (Static/Band Brake) |
750mt |
Secondary Winch Fibre Capacity - 160mm |
2 x 3700m of 160mm |
Chain Locker |
6x167m³ = 1002m³ |
Gypsies |
2 x 76mm, 1 x 84mm, 1 x 86mm, 1 x 111mm, 1 x 120mm, 1 x 147mm |
Shark Jaws |
2 x 800 MWL - Rolls Royce |
Shark Jaws Insert |
50mm - 166mm |
Tow Pins |
4 x 400 MWL - Rolls Royce |
Smit Bracket |
500mt MWL |
Secondary Winch Number of Drums |
2 Drums |
Secondary Winch Brake |
210mt |
Secondary Winch Max Weight |
200mt |
Pot Water |
888m³ / 5586bbls |
ROV Hangar |
Starboard side |
ROV system |
WROV |
