Subsea

Normand Sentinel

  • 1800m2
  • 350mt
  • 130
Built 2015
Design Vard 3 07
Flag NIS
Total Accommodation 130 Persons (130 x 1 Person)
LOA 142,6m
Breadth Moulded 25m
Cargo Deck Area Flat weldable steeldeck 1800m²
ROV Yes
Yard VARD Langsten
Main Class +1A1, SF, E0, DK(+), COMF-V(2)C(3), SPS, CLEAN DESIGN, DYNPOS-AUTRO, NAUT-AW, ICE-C, TMON, VIBR, BIS, CRANE, HELDK-SH (CAA-N), ESV-DP(HIL)
Classification Society DNV GL
Dynamic Positioning DP 3 from Rolls Royce
Helideck Diameter 26,1m, SWL 15mt - Sikorsky 92
Draft (max) 8m + 0m Skeg/Nozzle
Deck Cargo Capacity 5850mt (CoG 1,0m above main deck)
Deck Strength Main dk:Fr.#-12-#52 15mt/m2. FR#52-#84 10mt/m2. FR#84-#110 15mt/m2 A-dk: Fr #110-120 5mt/m²
Deadweight 9200mt (d=8m)
Moonpool 51,84m² (7,2 m x 7,2 m)
ROV system 2 WROVs
Main Crane SWL 250mt@ 17m - Single fall - AHC
Main Crane Aux winch SWL 350/20mt@ 12/40m - Single fall - AHC
Crane 2 SWL 50mt@ 11m - Single fall - AHC
Crane 2 Aux winch SWL 10mt@ 21m - Single fall - AHC
